AGL All Member Meeting Japan 2018 Breakout session & Showcase

EVENT

NTT DATA MSE Corporation will make a breakout session and a demonstration at the Automotive Grade Linux All Member Meeting (: AMM), which will be held from Feb. 20th, 2018 in Tokyo, Shinjuku, hosted by Automotive Grade Linux (: AGL) and The Linux Foundation.

In the breakout session, Hiroto Imamura, Manager, and Daisuke Nomura, Deputy Manager will give a presentation on ” Solution Approach in Integration of AI Engine into AGL “.

We will exhibit two demonstration systems at our booth.

  1. Integration of AI engine into AGL and Verification of the Possibility of the Edge AI
  2. Implementation SDL application (Movie playback / Map) onto AGL and Leveraging vehicle Data with SmartDeviceLink™ (: SDL)

Event Information

Time                   Feb. 20th (Tue.) through Feb. 21st (Web.)
Venue                 Hilton Tokyo
                             http://hiltonhotels.jp/hotel/kanto/hilton-tokyo
URL                    Automotive Grade Linux
                             https://www.automotivelinux.org/
                             The Linux Foundation
                             https://www.linuxfoundation.jp/
                             Automotive Grade Linux All Member Meeting
                             https://events.linuxfoundation.jp/events/agl-member-meeting/

Breakout session Information

Time                   Feb. 21st (Wed.) 13:00 – 13:50
Presenter           Hiroto Imamura – Manager
                             Daisuke Nomura – Deputy Manager
                             NTT DATA MSE Corporation
Overview            Solution Approach in Integration of AI Engine into AGL

Demonstration

Title 1

Integration of AI engine into AGL and Verification of the Possibility of the Edge AI

Overview

In order to verify the possibility of realizing Edge AI, i.e., use AI on edge devices, our company has implemented the handwritten number recognition application on AGL. The application crops a specific area of an USB camera image and shows inference result of an AI Engine. The deep learning framework which is called Neural Network Libraries (NNabla)*1 has been used as the AI Engine. By applying data augmentation*2 technique to the training data set and pre-processing of the camera image, recognition rate has been improved.
Processing time of the inference by the AI engine is about 2 ms*2. Our company has confirmed the possibility of utilizing Edge AI for various use-cases in the future.

Figure 1. Overview of ” Integration of AI engine into AGL and Verification of the Possibility of the Edge AI “

Title 2

Implementation SDL application (Movie playback / Map) onto AGL and Leveraging vehicle Data with SDL

Overview

  1. SDL application (Movie Playback / Map)
    Our company implemented Movie Playback application and Map application for SDL onto AGL. As a measure against driver distraction*4, contents on a display can be switched using vehicle data acquired via IVI systems.
  2. Collaboration
    Aiming at further development of AGL, we collaborated with DENSO TEN, which is a member of AGL on building a demonstration system.
    *Solutions: CAN Simulator, Vehicle Data Management

Figure 2. Overview of “Implemented SDL application and leverage vehicle data”

  • SDL application is a mobile application that works on both Android™ and iOS™ platforms and supports Movie Playback and Map Display.
  • Vehicle data which is acquired with SDL is uploaded to the cloud (AWS) via a smartphone and it can be browsed using computers or mobile devices.
  •  As a countermeasure against driver distraction, contents on a display are switched while driving according to the acquired vehicle data.

*1 https://github.com/sony/nnabla
*2 Technique to increase number of data of training data sets
*3 Measurement result on R-Car Starter Kit Premier
*4 The diversion of attention away from activities critical for safe driving

Our company will contribute to drive commercialization and practical realization of both AGL and SDL forward through organizing and performing collaboration with the other AGL related companies or function extension.
